Ply Gem

Vista Series

— Vinyl

Ply Gem

Vista Series

— Vinyl

Slimline design.  Expanded views.  Ply Gem’s Vista Series vinyl windows offer superior performance at an entry level price point.

How To Buy

Vista Series

Features & Benefits

  • Vinyl extrusions are formulated to withstand the harshest climates year after year and their multi-chambered design optimizes both strength and thermal efficiency.
  • Continuous head and sill designs for a water tight frame.
  • Double glazing available with a variety of glass options to maximize energy efficiency.
  • Casements and Awnings feature Triple weather-stripping on operating sashes provides ultimate protection against air and water infiltration to maximize energy efficiency.
  • Sleek Truth Classic® hardware conveniently folds away and will not interfere with most window coverings.
  • Available in white or beige.
  • Concealed multi-point locking system is standard on casement windows ensures consistent seal from top to bottom with a convenient single lock lever, as well as added protection against forced entry.
  • Colour-matched to hardware chosen.
  • Special egress hardware available for casement windows.
  • Sliders feature Tri-Fin weather-stripping on operating sash provides superior seal without compromising smooth operation.
  • Sliders utiliaze robust, centre-mounted knife latch lock is easily operated and provides excellent security.
  • Dual locks featured on units of greater height or width. Steel reinforcement added to pull rail and interlock on all horizontal sliders.
  • Sliders come with anti-lift sash to provide additional security.
  • To increase the curb appeal of your home, choose from multiple grille types in an array of colours and patterns.
  • A wide variety of interior and exterior accessories available.

Double Glazing is standard on Vista Series Windows. Choose from a variety of energy efficient ECO Glass options to suit your needs:

ECO GAIN 180 High Solar Gain Glass

When the weather turns frigid, Eco Gain 180 is the perfect cold remedy! Eco Gain 180 provides excellent insulating capability by blocking heat loss to the outside and reflecting heat back into the room. It is the ideal glass for passive solar applications as it allows the winter sun’s heat to pass into the home and provide “free heat.” It also blocks 76% of the sun’s harmful UV rays.

ECO SHIELD 270 Solar Control Glass

When it comes to solar control, the sun does not stand a chance against Eco Shield 270. It is the perfect glass for fighting the heat. Eco Shield 270 reduces solar heat gain by 50% or more compared to ordinary glass in the summer and keeps homes cozy by blocking heat loss in the winter. It blocks 86% of the sun’s UV rays yet lets light stream in due to its exceptional clarity without a heavy bronze or smokecolored tint to spoil the image.

ECO MAX SHIELD 366 Ultimate Performance Glass

Eco Max Shield 366 has been specially formulated to reject the summer sun’s heat without affecting the view. It lets more light in and keeps more heat out so homes stay cool and comfortable – with no room-darkening tints and virtually no exterior reflectance. The ultimate in solar control and clarity! Eco Max Shield 366 provides the highest levels of year-round comfort and energy savings, making it the perfect glass no matter where you live. It sports an unprecedented three layers of silver which reduce solar gain, reflect furnace heat back into the room and let light stream in.


ECO TINT 240 Glare Control Glass

Eco Tint 240 is a specially treated version of Low E glass that provides effective glare control and maximum solar heat blockage – without creating discomfort near the glass inside, or the visual nuisance of highly reflective glass outside. It also maintains year-round comfort, blocking oppressive solar heat gain and maintaining cool glass temperatures in summer, as well as warm inside glass temperatures in winter.

Click here for more Glass information.

Grille Patterns

  • Prairie

  • Craftsman

  • Ladder

  • Colonial

  • Perimeter Prairie

In-Glass Grille Styles

  • 5/16" Flat

  • 5/8" Flat

  • 3/4" Contour

  • 1" Contoured

  • 13/16" Flat

  • 1" Flat

Exterior Grille Styles

  • 2" Simulated Divided Mullion

  • 1" Simulated Divided Lite

Truth Classic™ Casement & Awning Window Hardware

Sliders utiliaze robust, centre-mounted knife latch lock is easily operated and provides excellent security.

  • White

  • Beige
